Description
HIGH-PERFORMANCE LED LIGHT BAR. The Baja Designs 10-Inch OnX6+ LED Light Bar with lower grille mounting brackets provides powerful illumination with its 10,817 lumen output for enhanced visibility. Designed specifically for off-road and night driving conditions, it delivers a combined spot and flood beam pattern for optimal lighting coverage.
CONSTRUCTION AND APPEARANCE. Crafted with aircraft-grade aluminum housing featuring a mil-spec hard anodized finish, the light bar offers superior durability and corrosion resistance. The clear hardcoated polycarbonate lens protects internal LEDs, while the billet machined aluminum bezel adds a premium aesthetic and rugged sturdiness.
INSTALLATION. Installation is straightforward and requires minimal modification to the vehicle, with no drilling needed for mounting brackets specifically designed to fit the Ford F-150 Raptor’s lower grille. The included upfitter wiring harness allows clean integration with factory switches.
WARRANTY. This product carries a lifetime limited warranty for long-term reliability and customer peace of mind.
APPLICATION. Designed exclusively to fit the 2017-2020 Ford F-150 Raptor lower grille area; note that the supplied brackets only support this exact light bar model and do not accept other light configurations.
Baja Designs 447557
CA Residents: WARNING: Cancer and Reproductive Harm
- OnX6+ 10-Inch LED Light Bar Driving Combo Clear
- Two Mounting Brackets Included
- Upfitter Wiring Harness 640094 Included
- All Necessary Mounting Hardware Supplied
- 106.26 Watts Power Consumption
- High Brightness Output of 10,817 Lumens, Low Brightness 9,230 Lumens
- Beam Pattern is Driving/Combo
- Housing Made from Aircraft Grade Aluminum with Mil-Spec Hard Anodize
- Lens Material is Hardcoated Polycarbonate
- Lens Color Clear
- Bezel Made from Billet Machined Aluminum
- Lighting Technology LED with Six Individual Lights
- Forward Projecting Light Type
- Stainless Steel Mounting Hardware
- Built-in Overvoltage Protection
- Average Rated Life Almost 50,000 Hours
- Amperage Rating 7.7 Amps
- Durability Exceeds MIL-STD-810G
- Impact Resistance IK10 Compliant
- Water Resistance IP69K Certified, Waterproof up to 9 Feet and Pressure Washable
- Weight 4.25 Pounds
- Dimensions: Length 10 Inches, Depth 4.29 Inches, Height 2.69 Inches
- Wiring Harness Hi-Low Dongle Not Included
- Fits 2017-2020 F-150 Raptor Lower Grille Area Only; Brackets Do Not Accept Other Lights
| Brand | Baja Designs |
| Bulb Type | LED |
| Light Shape | Square |
| Light Size | 3 to 3.75 Inch |
